Hardware Configuration
RUBY-9715VG2AR User’s Manual 2-20
J29/J30/J31/J32 : Primary/Secondary/3rd/4th SATA Connector
PIN No. Signal Description
1 Ground
2 SATATX+ (SATATXP)
3 SATATX- (SATATXN)
4 Ground
5 SATARX- (SATARXN)
6 SATARX+ (SATARXP)
7 Ground
J35 : SMBus Connector
PIN No. Signal Description
1 SMBus Clock
2 N/C
3 Ground
4 SMBus Data
5 +3V Stand-by
J36 : IrDA Connector
PIN No. Signal Description
1 +5V
2 N/C
3 IRRX
4 Ground
5 IRTX
6 N/C
J37 : SYSTEM Fan Connector
PIN No. Signal Description
1 Ground
2 +12V
3 Fan Speed Detecting signal
4 Fan Control Signal
Note:
The fan must be a 12V fan. And there is no over current protection.
