Power Electronics SD700 Series Hardware And Installation Manual

SD700 SERIES
POWER ELECTRONICS
12
CONFIGURATION TABLE & STANDARD RATINGS
2. CONFIGURATION TABLE & STANDARD
RATINGS
2.1. Configuration table
EXAMPLE
CODE: SD703705212T
SD7
0370
5
2
12
-
-
T
-
SERIE
Output
current
[1]
Input
Voltage
Degree of
protection
Pulses
number
Cabinet
Plinths
[2]
EMC Filter
Floating
Earth
Input
Frequency
SD7
SD700
0050
50A
2
230VAC
2
IP20
-
6
Pulses
-
Standard
-
Second
Environment
-
Without
floating
earth
-
50Hz
0100
100A
5
380-
500VAC
5
IP54
12
12
Pulses
20
Total
Height
2000mm
F
First
Environment
[3]
T
With
floating
earth
6
60Hz
[4]
…
…
7
525VAC
18
18
Pulses
22
Total
Height
2200mm
M
Optional
IT Filter
6
690VAC
24
24
Pulses
GENERAL CONSIDERATIONS:
[1] Verify the rated current of the motor nameplate to guarantee the compatibility with the selected drive.
[2] SD700 frame 4 only available with 1712mm total height.
[3] Floating earth drive not available with first environment filter.
[4] Consult availability.
CODIFICATION EXAMPLES:
o SD718006212 SD700, 1800A, 690Vac, Degree of protection IP20, 12 pulses, Second Environment, 50Hz.
o SD718006212F SD700, 1800A, 690Vac, Degree of protection IP20, 12 pulses, First environment, 50 Hz.
o SD701002518M SD700, 100A, 230Vac, Degree of protection IP54, 18 pulses, IT filter, 50Hz.
The following figure shows an example of designation label:
Figure 2.1 Type designation label (located on lateral panel)
