12. OPTIONAL EQUIPMENT
12.1. Accessories
Profibus Communication Board.
Ethernet Communication Board.
DeviceNet Communication Board.
CAN Open Communication Board.
N2 Metasys Communication Gateway.
Encoder Board.
It allows connecting up to 2 differential Encoders (one of them for the user and the other one for
vector control) working from 5 to 24VDC, according to the requirements.
Inputs / Outputs Expansion Board.
It allows increasing the number of inputs and outputs of the drive. It includes:
4 Programmable Digital Inputs optically isolated
1 Programmable Analogue Input
5 Digital Outputs (Relays)
1 Programmable Analogue Output
Fibre Optic Board. It allows to communicate trough fiber optics multiple drive in a master slave
configuration.
Safe Torque Off (STO) board. Allows implementing in the drive the safe torque off function
according to IEC 61800-5-2 (SIL1 or SIL3).
External 24V
DC
Power Supply.
For Frames 1, 2 and 3 of SD700. Exterior Assembly. Requires SD7EBI
External 24V
DC
Power Supply.
For Frame 4 of SD700. Interior Assembly.
External 24V
DC
Power Supply.
For Frame 5 of SD700. Interior Assembly.
External 24V
DC
Power Supply.
For Frames 6, 7, 9 and 10 of SD700. Interior Assembly.
External 24V
DC
Power Supply.
For Frame 8 and 11 of SD700. Interior Assembly.
Touch-Graphic Display.
(For further information, see section ’12.5 Touch-Graphic Display’).
Kit 3 meters Extender for Display.
Kit 5 meters Extender for Display.
GSM Module.
(For Touch-Graphic Display option).
Dynamic Braking Unit.
(For further information, see section ‘12.4 Dynamic Braking Unit B150’).
Optional Board for Slave Mode Brake.
(For Dynamic Braking Unit B150 option).
Consult availability with Power Electronics.
