POWER ELECTRONICS
SD700 SERIES
MECHANICAL INSTALLATION
27
5. MECHANICAL INSTALLATION
CAUTION
The installation must be done by qualified personal.
Otherwise, the equipment can be damaged and lead to injury to people.
5.1. Environmental ratings
It is recommended to follow the instructions of this manual to ensure the correct operation of the drive. The
installer has the responsibility of a properly indoor installation to ensure the ambient conditions of the VFD.
Additionally, the installer is ultimate responsible of the local regulation fulfilment. The environmental ratings
are the following ones:
 Environmental category: Indoor
 Wet locations: No
 Pollution degree: PD3
 Ingress protection rating: Clean zone: Electronics IP54 or IP20
Power connection and Input filters: IP20
 Operation Ambient temperature: -20ºC to 50ºC Heavy duty
-20ºC to 40ºC Normal Duty
 Storage Ambient temperature: -40ºC to 70ºC
 Humidity: 10 % to 95 % (non condensing)
 Heating resistors: Optionals
 Maximum altitude and power derating: 1000m 1% PN(kW) per 100m; 4000m maximum
 Vibration (IEC60068-2-6): Amplitude ± 1mm (2Hz – 13.2Hz), ±0.075 (13.2Hz –
57Hz)
Acceleration 6.86m/s² (13.2Hz-57Hz), 9.8m/s
2
(57Hz-
150Hz)
 Audible Noise: < 79dB
 Overvoltage category: III
 Protection class: Class 1
 Painting: Standard colour RAL 7047 in the front part and
RAL 7016 in the rear part, other under request
