Power Electronics SD700 Series Hardware And Installation Manual

SD700 SERIES
POWER ELECTRONICS
82
OPTIONAL EQUIPMENT
12.2. Extension Box
FRAME
CODE
Dimensions (mm)
W
H
D
1
SD7EB1
189
122
161
2
SD7EB2
295
122
161
3
SD7EB3
300
151
168
Figure 12.1 Dimensions for Extension Box
12.3. Plinths
FRAME
CODE
Dimensions (mm)
Total Drive
Height
(mm)
W
H
D
4
SD7PL0417
320
464
438.5
1712
5
SD7PL0520
431
413.5
529
2000
SD7PL0522
431
613.5
529
2200
6
SD7PL0620
786
413.5
529
2000
SD7PL0622
786
613.5
529
2200
7
SD7PL0720
1132
413.5
529
2000
SD7PL0722
1132
613.5
529
2200
8
SD7PL0820
1482
413.5
529
2000
SD7PL0822
1482
613.5
529
2200
9
SD7PL0920
3 x SD7PL0620
2000
SD7PL0922
3 x SD7PL0622
2200
10
SD7PL1020
3 x SD7PL0720
2000
SD7PL1022
3 x SD7PL0722
2200
11
SD7PL1120
3 x SD7PL0820
2000
SD7PL1122
3 x SD7PL0822
2200
Code Explanation: SD7PL0520
SD7
PL05
20
SD700 Series
Plinth for Frame 5
Total Height 2000mm
Figure12.2 Dimensions for Plinths
