POWER ELECTRONICS
TECHNICAL CHARACTERISTICS
23
SD700 SERIES
HARDWARE
DIGITAL INPUTS
6 programmable, Active high (24Vdc), Isolated power supply
1 PTC input
DIGITAL OUTPUTS
3 programmable changeover relays (250Vac, 8A or 30Vdc, 8A)
ANALOGUE INPUT
2 programmable differential inputs. 0 20mA, 4 20mA, 0 10Vdc and 10Vdc.
(Optically isolated)
ANALOGUE OUTPUTS
2 isolated programmable outputs: 0 20mA, 4 20mA, 0 10Vdc and 10Vdc
ENCODER INPUTS (Optional)
Two differential encoders input. Voltages inputs from 5 to 24Vdc
USER POWER SUPPLY
+24Vdc user power supply ( Max 180mA) regulated and short-circuit protected
+10Vdc user power supply (Max 2 potentiometers R= 1 k) regulated and short-circuit
protected
I/O EXTENSION BOARD
(Optional)
4 Digital Inputs: Programmable inputs and active high (24Vdc). Optically isolated.
1 Analogue Input: Programmable and differential input.
5 Digital Outputs: programmable multi-function relays.
1 Analogue Output: Programmable outputs in voltage / current.
EXTERNAL POWER SUPPLY
(Optional)
24 V External Power Supply, Fault Relay integrated
COMMUNICATION
STANDARD HARDWARE
USB port
RS232 port
RS485 port
OPTIONAL HARDWARE
Optical fiber
Ethernet
STANDARD PROTOCOL
Modbus-RTU
OPTIONAL PROTOCOL
Profibus-DP
DeviceNet
Ethernet (Modbus TCP)
Ethernet IP
CAN Open
N2 Metasys Gateway
CONTROL PANEL
TYPE
Removable
LENGTH
3 meters and 5 meters (optional)
CONNECTION
RJ45
VISUALIZATION LEDS
LED ON: Control board is energized
LED RUN: Motor receiving power supply
LED FAULT: Flashing displays that a fault has occurred
ALPHANUMERIC DISPLAY
4 lines x 16 characters
Keypad with 6 keys to control and configure the drive, start and stop/reset
Independent memory
TOUCH AND COLOUR GRAPHIC
DISPLAY (Optional)
Optional Colour touch-screen display 3.5
4Gbytes Micro SD for register and notification of faults, events and configurations.
Quad band GSM modem / Start, Stop, reset and remote consultations with SMS.
Ethernet RJ45 dual connection, micro-USB connection
Possibility of external or battery 5Vdc power supply
DISPLAY INFORMATION
Average current and 3-phase motor current
Average voltage and 3-phase motor voltage
Average input voltage and 3-phase input voltage
3-phase input and output frequency
DC Bus Voltage
Drive Status
Speed, Torque, Power, Power factor of motor
Register of total and partial drive running time with reset function. (hours)
Register of total and partial drive energy consumption with reset function (kWh)
Relay status
Digital inputs / PTC status
Output comparator status
Analogue inputs and sensor values
Analogue output value
Motor overload and equipment status
Drive and rectifier temperature
Fault history (last 6 faults)
OTHERS
Real time clock
Perpetual calendar
