Power Electronics SD700 Series Hardware And Installation Manual

POWER ELECTRONICS
SD700 SERIES
DIMENSIONS
75
10.2. Dimensions of Frames 3, 4 and 5
FRAME
INPUT VOLTAGE
EQUIPMENTS
3
230VAC (±20%)
SD70064 2X Y, SD70075 2X Y, SD70090 2X Y, SD70115 2X Y
380 – 500VAC (-20% to +10%)
SD70060 5X Y, SD70075 5X Y, SD70090 5X Y, SD70115 5X Y
525VAC (-20% to +10%)
-
690VAC (-15% to +10%)
SD70052 6X Y, SD70062 6X Y
4
230VAC (±20%)
SD70150 2X Y, SD70170 2X Y
380 – 500VAC (-20% to +10%)
SD70150 5X Y, SD70170 5X Y
525VAC (-20% to +10%)
SD70100 7X Y, SD70120 7X Y, SD70145 7X Y
690VAC (-15% to +10%)
SD70080 6X Y, SD70105 6X Y
5
230VAC (±20%)
SD70210 2X Y, SD70250 2X Y, SD70275 2X Y
380 – 500VAC (-20% to +10%)
SD70210 5X Y, SD70250 5X Y, SD70275 5X Y
525VAC (-20% to +10%)
SD70180 7X Y, SD70205 7X Y
690VAC (-15% to +10%)
SD70130 6X Y, SD70150 6X Y, SD70170 6X Y
FRAME
DIMENSIONS (mm)
WEIGHT
(kg)
H1
H2
W1
W2
W3
D1
D2
Y1
Y2
Y3
Y4
3
853.5
838.5
300.5
200
140
358
-
827
15
-
-
67.5
4
1245
1206
320
251
-
438.5
-
881
527.5
353.5
-
94
5
1712
1667
431
396
-
529
460
1403.5
1240.5
81.5
-
200
Figure 10.3 Dimensions of Frame 3 Figure 10.4 Dimensions of Frame 4
Figure 10.5 Dimensions of Frame 5
