RECEPTION, HANDLING AND TRANSPORTATION
4. RECEPTION, HANDLING AND
TRANSPORTATION
CAUTION
Read carefully the following installation instructions for a correct mechanical installation.
Otherwise, the equipment can be damaged and lead to injury to people.
4.1. Reception and Storage
The SD700 are carefully tested and perfectly packed before delivering. In the event of transport damage,
please ensure that you notify the transport agency and Power Electronics: 902 40 20 70 (International +34
96 136 65 57) or your nearest agent, within 24hrs from receipt of the goods.
Make sure model and serial number of the drive are the same on the delivery note and unit.
Drive’s storage should be sun and moisture protected and with an ambient temperature between
-40°C and +70°C, < 95 RH without condensation. It is recommended not pile more than two units.
4.2. Handling and Transportation
Only the transport methods described in this document or in the delivery notes are permissible. Any other
transport method or system could damage the unit.
SD700 is delivered horizontally. Frames 1 and 2 are delivered in a cardboard box and frames 3 on are
delivered fastened to a wooden pallet, covered with a cardboard box in frames 3 and 4 or with a wooden
box in frames 5 on. Depending on the transport method, the drive could be moisture protected with a
vacuum plastic bag. Move the complete pallet as close as possible to its final installation place before
unpacking, to avoid any damage during transportation.
It is mandatory to transport it with a pallet truck, forklift or crane fork, taking care about the load distribution
and centre of gravity. Check the size and weight of VFD components to choose proper lifting equipment
with a capacity greater than the drive weight.
Unpack the drive carefully. Do not use edge tool to protect the product from damage. After open the
package, please check the goods contained. Verify the item numbers contained within the package with
the packing inventory list. Please set aside and reserve, if contained, the case of spare parts shipped with
the product. There should be no evident damage caused by vibration, dropping or moisture.
CAUTION
If the maximum tonnage of cranes cannot meet the requirement, it could cause damage to the
equipment and lead to injury to people.
