Power Electronics SD700 Series Hardware And Installation Manual

SD700 SERIES
POWER ELECTRONICS
18
CONFIGURATION TABLE & STANDARD RATINGS
18 PULSES
FRAME
CODE
Operation Temperature 50ºC
HEAVY DUTY
Operation Temperature 40ºC
NORMAL DUTY
I(A)
Rated
Motor
Power (kW)
at 500VAC
150%
Overload
(A)
I(A)
Rated
Motor
Power (kW)
at 500VAC
120%
Overload
(A)
7
SD70580 5X 18 Y
464
315
696
580
355
696
SD70650 5X 18 Y
520
355
780
650
400
780
SD70720 5X 18 Y
576
400
864
720
450
864
9
SD71150 5X 18 Y
920
630
1380
1150
710
1380
SD71260 5X 18 Y
1008
710
1512
1260
800
1512
SD71440 5X 18 Y
1152
800
1728
1440
900
1728
10
SD71580 5X 18 Y
1264
900
1896
1580
1000
1896
SD71800 5X 18 Y
1440
1000
2160
1800
1200
2160
11
SD72200 5X 18 Y
1760
1200
2640
2200
1500
2640
SD72500 5X 18 Y
2000
1400
3000
2500
1750
3000
24 PULSES
FRAME
CODE
Operation Temperature 50ºC
HEAVY DUTY
Operation Temperature 40ºC
NORMAL DUTY
I(A)
Rated
Motor
Power (kW)
at 500VAC
150%
Overload
(A)
I(A)
Rated
Motor
Power (kW)
at 500VAC
120%
Overload
(A)
8
SD70840 5X 24 Y
672
450
1008
840
500
1008
SD70925 5X 24 Y
740
500
1110
925
560
1110
SD70990 5X 24 Y
767
560
1151
959
630
1151
11
SD72200 5X 24 Y
1760
1200
2640
2200
1500
2640
SD72500 5X 24 Y
2000
1400
3000
2500
1750
3000
2.6. Standard ratings – 525Vac
6 PULSES
FRAME
CODE
Operation Temperature 50ºC
HEAVY DUTY
Operation Range 40ºC
NORMAL DUTY
I(A)
Rated
Motor
Power (kW)
at 525VAC
150%
Overload
(A)
I(A)
Rated
Motor
Power (kW)
at 525VAC
120%
Overload
(A)
4
SD70100 7X Y
100
75
150
122
90
150
SD70120 7X Y
120
90
180
147
110
180
SD70145 7X Y
145
110
218
176
132
218
5
SD70180 7X Y
180
132
270
222
150
270
SD70205 7X Y
205
150
308
254
185
308
6
SD70270 7X Y
270
200
405
334
250
405
SD70295 7X Y
295
220
443
360
280
443
SD70340 7X Y
340
250
510
417
315
510
7
SD70425 7X Y
425
315
638
526
400
638
SD70470 7X Y
470
355
705
586
450
705
SD70535 7X Y
535
400
803
666
500
803
8
SD70660 7X Y
660
500
990
824
600
990
SD70750 7X Y
750
560
1125
936
700
1125
9
SD70845 7X Y
845
630
1268
1052
800
1268
SD70950 7X Y
950
710
1425
1157
900
1425
10
SD71070 7X Y
1070
800
1605
1337
1000
1605
SD71205 7X Y
1205
900
1808
1504
1100
1808
SD71340 7X Y
1340
1000
2010
1672
1250
2010
SD71605 7X Y
1605
1200
2408
2006
1500
2408
11
SD72005 7X Y
2005
1500
3008
2507
1900
3008
