CONFIGURATION TABLE & STANDARD RATINGS
2.7. Standard ratings – 690Vac
6 PULSES
FRAME
CODE
Operation Temperature 50ºC
HEAVY DUTY
Operation Temperature 40ºC
NORMAL DUTY
I(A)
Rated
Motor
Power (kW)
at 690VAC
150%
Overload
(A)
I(A)
Rated
Motor
Power (kW)
at 690VAC
120%
Overload
(A)
4
SD70052 6X Y
52
45
78
65
55
78
SD70062 6X Y
62
55
93
78
75
93
SD70080 6X Y
80
75
120
100
90
120
SD70105 6X Y
105
90
157
131
110
157
5
SD70130 6X Y
130
110
195
163
132
195
SD70150 6X Y
150
132
225
188
160
225
SD70170 6X Y
170
160
255
213
200
255
6
SD70210 6X Y
210
200
315
263
250
315
SD70260 6X Y
260
250
390
325
315
390
SD70320 6X Y
320
315
480
400
355
480
7
SD70385 6X Y
385
355
578
481
450
578
SD70460 6X Y
460
450
690
575
500
690
8
SD70550 6X Y
550
500
825
688
630
825
SD70660 6X Y
660
630
990
825
800
990
9
SD70750 6X Y
750
710
1125
938
900
1125
SD70840 6X Y
840
800
1260
1050
1000
1260
SD70950 6X Y
950
900
1425
1188
1100
1425
10
SD71140 6X Y
1140
1000
1710
1425
1300
1710
SD71270 6X Y
1270
1200
1905
1588
1600
1905
SD71420 6X Y
1420
1400
2130
1775
1700
2130
11
SD71500 6X Y
1500
1500
2250
1875
1800
2250
SD71800 6X Y
1800
1800
2700
2250
2000
2700
12 PULSES
FRAME
CODE
Operation Temperature 50ºC
HEAVY DUTY
Operation Temperature 40ºC
NORMAL DUTY
I(A)
Rated
Motor
Power (kW)
at 690VAC
150%
Overload
(A)
I(A)
Rated
Motor
Power (kW)
at 690VAC
120%
Overload
(A)
6
SD70210 6X 12 Y
210
200
315
263
250
315
SD70260 6X 12 Y
260
250
390
325
315
390
SD70320 6X 12 Y
320
315
480
400
355
480
8
SD70550 6X 12 Y
550
500
825
688
630
825
SD70660 6X 12 Y
660
630
990
825
800
990
9
SD70750 6X 12 Y
750
710
1125
938
900
1125
SD70840 6X 12 Y
840
800
1260
1050
1000
1260
SD70950 6X 12 Y
950
900
1425
1188
1100
1425
11
SD71500 6X 12 Y
1500
1500
2250
1875
1800
2250
SD71800 6X 12 Y
1800
1800
2700
2250
2000
2700
