Power Electronics SD700 User Manual

POWER ELECTRONICS
SD700FR SERIES
DESCRIPTION OF PROGRAMMING PARAMETERS
37
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
1 SEL RELAY 1=02
G8.1.1 /
Selection of
Relay 1 control
source
00 – 40
Note: Coming from the previous page.
OPT
DESCRIPTION
FUNCTION
32
CRANE
BRAKE
The relay will be activated like in
option “05 RUN”, considering the
ON delay time set in G8.1.2, G8.1.6
or G8.1.10 (depending on the used
Relay 1, 2 or 3), and will be
deactivated when the motor speed
is below the speed set in G8.1.13.
33
PIPE FILLING
In pump application the relay is
energized when the application
state is pipe filling.
34
WARNING
The relay is energized when there is
any Warning.
35
COPY DI1
Copies the corresponding digital
input and closes the relay when the
digital input is active.
36
COPY DI2
37
COPY DI3
38
COPY DI4
39
COPY DI5
40
COPY DI6
YES
2 T R1 ON=0.0s
R1 ACTIVAT DELAY
G8.1.2 / ON
delay time for
Relay 1
0.0 – 999s
Allows user to set a delay time before activating relay 1.
If during this ON delay time the activation condition disappears, the relay will not
be activated.
YES
3 T R1 OFF=0.0s
R1 DEACTIV DELAY
G8.1.3 / OFF
delay time for
Relay 1
0.0 – 999s
Allows user to set a delay time before deactivating relay 1.
If during this OFF delay time the deactivation condition disappears, the relay will
follow activated.
YES
4 INVERT REL1=N
G8.1.4 / Relay 1
inversion
N
Y
It allows user to invert the logic of relay 1 functionality.
Relay 1 has one normally open contact (connection 26/27) and another normally
close contact (connection 27/28).
OPT
FUNCTION
N=NO
No inversion.
Y=YES
Inversion of relay logical function.
YES
5 SEL RELAY 2=03
G8.1.5 /
Selection of
Relay 2 control
source
00 – 40
Note: See parameter function of G8.1.1.
YES
6 T R2 ON=0.0s
R2 ACTIVAT DELAY
G8.1.6 / ON
delay time for
Relay 2
0.0 – 999s
Allows user to set a delay time before activating relay 2.
If during this ON delay time the activation condition disappears, the relay will not
be activated.
YES
7 T R2 OFF=0.0s
R2 DEACTIV DELAY
G8.1.7 / OFF
delay time for
Relay 2
0.0 – 999s
Allows user to set a delay time before deactivating relay 2.
If during this OFF delay time the deactivation condition disappears, the relay will
follow activated.
YES
8 INVERT REL2=N
G8.1.8 / Relay 2
inversion
N
Y
It allows user to invert the logic of relay 2 functionality.
Relay 2 has one normally open contact (connection 29/30) and another normally
close contact (connection 30/31).
OPT
FUNCTION
N=NO
No inversion.
Y=YES
Inversion of relay logical function.
YES
9 SEL RELAY 3=05
G8.1.9 /
Selection of
Relay 3 control
source
00 – 40
Note: See parameter function of G8.1.1.
YES
10 T R3 ON=0.0s
R3 ACTIVAT DELAY
G8.1.10 / ON
delay time for
Relay 3
0.0 – 999s
Allows user to set a delay time before activating relay 3.
If during this ON delay time the activation condition disappears, the relay will not
be activated.
YES
11 T R3 OFF=0.0s
R3 DEACTIV DELAY
G8.1.11 / OFF
delay time for
Relay 3
0.0 – 999s
Allows user to set a delay time before deactivating relay 3.
If during this OFF delay time the deactivation condition disappears, the relay will
follow activated.
YES
12 INVERT REL3=N
G8.1.12 / Relay
3 inversion
N
Y
It allows user to invert the logic of relay 3 functionality.
Relay 3 has one normally open contact (connection 32/33) and another normally
close contact (connection 33/34).
OPT
FUNCTION
N=NO
No inversion.
Y=YES
Inversion of relay logical function.
YES
13 CRAspdOF=+5.0%
CRANE BRKoff SPD
G8.1.13 / Speed
for disconnecting
relay in option
Crane
+0.0% to
+250%
This parameter allows setting the speed below which, any relay configured with
option „32 CRANE BRAKE‟ will be deactivated.
YES
