Power Electronics SD700 User Manual

POWER ELECTRONICS
SD700FR SERIES
MODBUS COMMUNICATION
67
Parameter
Screen
Description
Address
Range
Modbus
Range
G6.3
3 SEL FBK=AI2
Selection of feedback signal source
40143
NONE
AI1
AI2
RESERV
0 to 3
G6.4
4 GAIN Kp=8.0
Proportional gain of PID control
40144
0.1 to 20
1 to 200
G6.5
5 INTEGRAL = 0.0s
Integration time of PID control
40145
0.0 to 1000s; Max
0 to 10000;
10001
G6.6
6 DIFFEREN = 0.0s
Derivation time of PID control
40146
0.0 to 250s
0 to 2500
G6.7
7 INVERT PID=N
PID output inversion
40147
N
Y
0 to 1
G6.8
8 ERR PID = +0.0%
PID control error
40148
-
-
G7.1
1 STOP 1 = RAMP
Stop mode 1
40003
RAMP
SPIN
0 to 1
G7.2
2 STOP 2 = SPIN
Stop mode 2
40004
RAMP
SPIN
0 to 1
G7.3
3 BRK STP 2 = OFF
Changing speed for stop mode
40005
OFF=0 to 250%
0 to 20480
G7.4
4 START = RAMP
Start mode
40002
RAMP
SPIN
SPIN2
0 to 2
G7.5
5 START 2=RAMP
Start mode 2
40015
RAMP
SPIN
SPIN2
0 to 2
G7.6
6 STAR DLY = OFF
Start delay time
40006
OFF=0 to 6500s
0 to 65000
G7.7
7 STOP DLY = OFF
Stop delay time
40007
OFF=0 to 6500s
0 to 65000
G7.8
8 STP MIN SP = N
Minimum stop speed
40008
N
Y
0 to 1
G7.9
9 OFFdly = OFF
Delay time between stop and next start
40014
OFF=0.000 to 10.0s
0 to 10000
G7.10
10 RUN AFTR VFL =
Y
Run after occurring power loss
40009
N
Y
0 to 1
G7.11
11 SPNstr B = OFF
Accuracy setting for Starting by Spin
40017
OFF=0; 1 to 100%
0 to 1000
G7.12
12 OFFdly2 = OFF
Delay time for start command after stop
40031
OFF=0; 0.1 to 6500.0s
0 to 65000
G7.13
13 STR AFT RST=Y
Starting after fault reset with start command
40010
N
Y
0 to 1
G7.14
14 RPWr OFF = OFF
Power Off Delay
41852
OFF, 0.001 to 9.99
0-9990
G7.15
15 MagneT = OFF
Magnetization time
40404
OFF, 0.001 to 9.99
0-9990
G7.16
16 RetATR = OFF
Start Delay after Reset.
41561
OFF, 0.001 to 9.99
0-9990
G8.1.1
1 SEL RELAY 1=02
Selection of Relay 1 control source
40362
00 to 40
0 to 40
G8.1.2
2 T R1 ON=0.0s
ON delay time for Relay 1
40363
0.0 to 999s
0 to 9999
G8.1.3
3 T R1 OFF=0.0s
OFF delay time for Relay 1
40364
0.0 to 999s
0 to 9999
G8.1.4
4 INVERT REL1=N
Relay 1 inversion
40365
N
Y
0 to 1
G8.1.5
5 SEL RELAY 2=03
Selection of Relay 2 control source
40366
00 to 40
0 to 40
G8.1.6
6 T R2 ON=0.0s
ON delay time for Relay 2
40367
0.0 to 999s
0 to 9999
G8.1.7
7 T R2 OFF=0.0s
OFF delay time for Relay 2
40368
0.0 to 999s
0 to 9999
G8.1.8
8 INVERT REL2=N
Relay 2 inversion
40369
N
Y
0 to 1
G8.1.9
9 SEL RELAY 3=05
Selection of Relay 3 control source
40370
00 to 40
0 to 40
G8.1.10
10 T R3 ON=0.0s
ON delay time for Relay 3
40371
0.0 to 999s
0 to 9999
G8.1.11
11 T R3 OFF=0.0s
OFF delay time for Relay 3
40372
0.0 to 999s
0 to 9999
G8.1.12
12 INVERT REL3=N
Relay 3 inversion
40373
N
Y
0 to 1
G8.1.13
13 CRAspdOF=+5.0%
Speed for disconnecting relay in option Crane
40597
+0.0% to +250%
0 to 20480
G8.2.1
1 ANLG OUT1=01
Mode selection for Analogue Output 1
40342
00 to 27
0 to 27
G8.2.2
2 FORMT 1=4-20 mA
Format selection for Analogue Output 1
40343
0-10V
±10V
0-20mA
4-20mA
0 to 3
G8.2.3
3 MIN1 RNG=+0%
Low of range selection Analogue Output 1
40344
-250% to +250%
-20480 to
+20480
G8.2.4
4 MAX1 RNG=+100%
High range selection of Analogue Output 1
40345
-250% to +250%
-20480 to
+20480
G8.2.5
5 FILTER 1=OFF
Filter selection for Analogue Output 1
40346
OFF= 0.0 to 20.0s
0 to 200
G8.2.6
6 ANLG OUT 2=02
Mode selection Analogue Output 2
40347
00 to 27
0 to 27
G8.2.7
7 FORMT 2=4-20 mA
Format selection for Analogue Output 2
40348
0-10V
±10V
0-20mA
4-20mA
0 to 3
G8.2.8
8 MIN2 RNG=+0%
Low range selection of Analogue Output 2
40349
-250% to +250%
-20480 to
+20480
G8.2.9
9 MAX2 RNG=+100%
High range selection of Analogue Output 2
40350
-250% to +250%
-20480 to
+20480
