SD700FR SERIES
POWER ELECTRONICS
68
MODBUS COMMUNICATION
Parameter
Screen
Description
Address
Range
Modbus
Range
G8.2.10
10 FILTER 2=OFF
Filter selection for Analogue Output 2
40351
OFF=0.0 to 20.0s
0 to 200
G9.1.1
1 COMP 1 SEL=00
Source selection for Comparator 1
40302
00 to 22
0 to 22
G9.1.2
2 COMP 1 TYPE=0
Comparator 1 type selection
40303
0 to 1
0 to 1
G9.1.3
3 SP C1 ON=+100[%]
Activation value of Comparator 1 in Normal mode
40305
-250% to +250%
-20480 to
+20480
G9.1.4
4 LIM 2 C1=+100[%]
Limit 2 for Comparator 1 in Window mode
40305
-250% to +250%
-20480 to
+20480
G9.1.5
5 LIM 1 C1=+0[%]
Limit 1 for Comparator 1 in Window mode
40304
-250% to +250%
-20480 to
+20480
G9.1.6
6 T C1 ON=0.0s
ON delay time for Comparator 1
40306
0.0 to 999s
0 to 9999
G9.1.7
7 SP C1 OF=+0[%]
Deactivation value of Comparator 1 in Normal
mode
40304
-250% to +250%
-20480 to
+20480
G9.1.8
8 T C1 OF=0.0s
OFF delay time for Comparator 1
40307
0.0 to 9999s
0 to 99999
G9.1.9
9 SEL FUNT C1=00
Selection of output function for Comparator 1
40308
00 to 11
0 to 11
G9.2.1
1 COMP 2 SEL=00
Source selection for Comparator 2
40311
00 to 22
0 to 22
G9.2.2
2 COMP 2 TYPE=0
Comparator 2 type selection
40312
0 to 1
0 to 1
G9.2.3
3 SP C2 ON=+100[%]
Activation value of Comparator 2 in Normal mode
40314
-250% to +250%
-20480 to
+20480
G9.2.4
4 LIM 2 C2=+100[%]
Limit 2 for Comparator 2 in Window mode
40314
-250% to +250%
-20480 to
+20480
G9.2.5
5 LIM 1 C2=+0[%]
Limit 1 for Comparator 2 in Window mode
40313
-250% to +250%
-20480 to
+20480
G9.2.6
6 T C2 ON=0.0s
ON delay time for Comparator 2
40315
0.0 to 999s
0 to 9999
G9.2.7
7 SP C2 OF=+0[%]
Deactivation value of Comparator 2 in Normal
mode
40313
-250% to +250%
-20480 to
+20480
G9.2.8
8 T C2 OF=0.0s
OFF delay time for Comparator 2
40316
0.0 to 9999s
0 to 99999
G9.2.9
9 SEL FUNT C2=00
Selection of output function for Comparator 2
40317
00 to 11
0 to 11
G9.3.1
1 COMP 3 SEL=00
Source selection for Comparator 3
40320
00 to 22
0 to 22
G9.3.2
2 COMP 3 TYPE=0
Comparator 3 type selection
40321
0 to 1
0 to 1
G9.3.3
3 SP C3 ON=+100[%]
Activation value of Comparator 3 in Normal mode
40323
-250% to +250%
-20480 to
+20480
G9.3.4
4 LIM 2 C3=+100[%]
Limit 2 for Comparator 3 in Window mode
40323
-250% to +250%
-20480 to
+20480
G9.3.5
5 LIM 1 C3=+0[%]
Limit 1 for Comparator 3 in Window mode
40322
-250% to +250%
-20480 to
+20480
G9.3.6
6 T C3 ON=0.0s
ON delay time for Comparator 3
40324
0.0 to 999s
0 to 9999
G9.3.7
7 SP C3 OF=+0[%]
Deactivation value of Comparator 3 in Normal
mode
40322
-250% to +250%
-20480 to
+20480
G9.3.8
8 T C3 OF=0.0s
OFF delay time for Comparator 3
40325
0.0 to 9999s
0 to 99999
G9.3.9
9 SEL FUNT C3=00
Selection of output function for Comparator 3
40326
00 to 11
0 to 11
G10.1
1 MIN1 SP=+0.00%
Minimum speed limit 1
40102
-250% to Max.
speed 1
-20480 to
G10.2
G10.2
2 MAX1 SP=+100%
Maximum speed limit 1
40104
Min. speed 1 to +250%
G10.1 to
20480
G10.3
3 MIN2 SP=-100%
Minimum speed limit 2
40103
-250% to Max.
speed 2
-20480 to
G10.4
G10.4
4 MAX2 SP=+100%
Maximum speed limit 2
40105
Min. speed 2 to +250%
G10.3 to
20480
G10.5
5 I LIMIT=___A
Current limit
40106
0.25 to 1.50In, OFF
2048 to
12291
G10.6
6 I LIM TO= OFF
Trip time because of current limit
40453
0 to 60s, OFF
0 to 600; 610
G10.7
7 I. MAX2=____A
Alternative current limit
40109
0.25 to 1.50In, OFF
2048 to
12291
G10.8
8 MI2 brSP=OFF
Change speed for Imax 2
40110
OFF=0%; +1 to +250%
0 to 20480
G10.9
9 MAX TOR=+150%
Torque limit
40107
-250% to +250%
-20480 to
+20480
G10.10
10 T LIM TO=OFF
Trip time because of torque limit
40455
0 to 60s, OFF
0 to 600; 610
G10.11
11 INVERSION ?=N
To enable speed inversion
40108
N
Y
0 to 1
G11.1
1 SP LIM TO=OFF
Trip time because of speed limit
40452
0 to 60s, OFF
0 to 600, 610
G11.2
2 STOP TO=OFF
Maximum time for stop limit
40454
OFF=0.0 to 999s
0 to 9999
G11.3
3 GND I LIMIT=10%
Ground fault detection
40456
OFF, 0 to 30% In
0 to 2458
G11.4
4 LOW VOLT=360V
Low input voltage level
40457
323 to 425V
586 to 621V
400V
3230 to 4250
690V
5860 to 6210
G11.5
5 LOW V TO=5s
Trip time because of low input voltage
40458
0.0 to 60s, OFF
0 to 600; 610
G11.6
6 HIGH VOLT=500V
High input voltage level
40459
418 to 587V
726 to 759V
400V
4180 to 5870
690V
7260 to 7590
