Power Electronics SD700 User Manual

POWER ELECTRONICS
SD700FR SERIES
MODBUS COMMUNICATION
71
Parameter
Screen
Description
Address
Range
Modbus
Range
G20.4.6
6 ASM- OUT=20
Output assembly
41705
20
21
100
0-2
G20.4.7
7 DNst=UNUSED
DeviceNet State
41706
0 to 4
0 to 4
G21.1.1
1 AUTOMATIC IP=Y
To enable automatic assignation of parameters
40922
N or Y
0 to 1
-
Ixxx.yyy.zzz.hhh
Present IP address of the drive
40923 – A
40924 – B
40925 – C
40926 – D
-
-
-
Sxxx.yyy.zzz.hhh
Present Subnet Mask of the drive
40927 – A
40928 – B
40929 – C
40930 – D
-
-
-
Gxxx.yyy.zzz.hhh
Present Gateway of the drive
40931 – A
40932 – B
40933 – C
40934 – D
-
-
G21.1.2
2 IP MANU. A=192
IP address (A)
40374
0 to 255
0 to 255
G21.1.3
3 IP MANU. B=168
IP address (B)
40375
0 to 255
0 to 255
G21.1.4
4 IP MANU. C=1
IP address (C)
40376
0 to 255
0 to 255
G21.1.5
5 IP MANU. D=143
IP address (D)
40377
0 to 255
0 to 255
G21.1.6
6 SUBNET A=255
Subnet Mask address (A)
40378
0 to 255
0 to 255
G21.1.7
7 SUBNET B=255
Subnet Mask address (B)
40379
0 to 255
0 to 255
G21.1.8
8 SUBNET C=255
Subnet Mask address (C)
40380
0 to 255
0 to 255
G21.1.9
9 SUBNET D=0
Subnet Mask address (D)
40381
0 to 255
0 to 255
G21.1.10
10 GATEWAY A=0
Gateway address (A)
40382
0 to 255
0 to 255
G21.1.11
11 GATEWAY B=0
Gateway address (B)
40383
0 to 255
0 to 255
G21.1.12
12 GATEWAY C=0
Gateway address (C)
40384
0 to 255
0 to 255
G21.1.13
13 GATEWAY D=0
Gateway address (D)
40385
0 to 255
0 to 255
G21.1.14
14 MAC A=0
MAC address (A)
40386
0 to 255
0 to 255
G21.1.15
15 MAC B=80
MAC address (B)
40387
0 to 255
0 to 255
G21.1.16
16 MAC C=194
MAC address (C)
40388
0 to 255
0 to 255
G21.1.17
17 MAC D=114
MAC address (D)
40389
0 to 255
0 to 255
G21.1.18
18 MAC E=X
MAC address (E)
40390
0 to 255
0 to 255
G21.1.19
19 MAC F=Y
MAC address (F)
40391
0 to 255
0 to 255
G21.2.1
1 MIPtout=OFF
Communication timeout MODBUS TCP
41451
OFF=0 to 600s
0 to 600
G21.3.1
1 CONTROL MODE=0
Control mode of the drive
41401
LOCAL
NETWORK
NET DECIDES
0 to 2
G21.3.2
2 REFEREN.MODE=0
Reference mode of the drive
41402
LOCAL
NETWORK
NET DECIDES
0 to 2
G22.1
1 Vdc REF=600 for
Vin=380V/480V, 800
for Vin=525V, 1050 for
Vin=690V
Vdc Reference
41351
500Vdc to 825Vdc
or
650Vdc to 900Vdc
or
950Vdc to 1251Vdc
500 to 825
or
650 to 900
or
950 to 1251
G22.2
2 Cos phi=100
CosPHI Reference
41352
0.9 to 1
90 to 100
G22.3
3 CAP/IND=CAP
CosPHI CHAR
41353
CAP or IND
0 to 1
G22.4
4 FREQ RE=2800
Rect. frequency
41354
1500 to 8000
1500 to 8000
G22.5
5 TIME OFF=0.0
Delay OFF Rect.
41355
0.0s to 60.0s
0 to 600
G22.8
8 AD K=N
Active Damping K
41358
N or Y
0 to 1
G22.9
9 AD HPF=500
AD Filter
41359
50Hz to 1000Hz
50 to 1000
G22.10.1
1 Kp PLL=10.0
PID Kp PLL
41360
0.0 to 100.0
0 to 1000
G22.10.2
2 Ki PLL=15.0
PID Ki PLL
41361
0.0 to 100.0
0 to 1000
G22.10.3
3 Kp Vdc=10.0
PID Kp Vdc
41362
0.0 to 100.0
0 to 1000
G22.10.4
4 Ki Vdc=3.5
PID Ki Vdc
41363
0.0 to 100.0
0 to 1000
G22.10.5
5 Kp I=10.0
PID Kp I
41364
0.0 to 100.0
0 to 1000
G22.10.6
6 Ki I=10.0
PID Ki I
41365
0.0 to 100.0
0 to 1000
G22.11.5
5 I lim REC=1.5xIn
Current lim Rectifier
41376
1xIn to 2xIn
8192 to 12288
G22.11.6
6 T I Limit= OFF
Time Delay Current Limit Rect
41377
0 to 60s
OFF
0 to 61
G22.11.7
7 I Imb=30.0%
Current I Imbalance
41378
OFF
00.0%-50.0%
0 to 500
G22.11.8
8 I Gnd=30.0%
Ground current fault
41379
OFF
00.0%-50.0%
0 to 500
G22.12.1
1 LCL Mode=RUN
LCL filter mode operation
41374
RUN or POWER
0 to 1
G22.12.2
2 Pw RunLCL=20%
Power Run LCL filter
41375
10% to 100%
10 to 100
