SD700FR SERIES
CONFIGURATION REGISTER
93
PARAMETERS
FACTORY SETTINGS
SETTING 1
SETTING 2
9 LOW V BHV=1
1
___________________
___________________
10 PTC EXT ?=N
N
___________________
___________________
11 PUMP OV=20.0A
PUMP OVERLOAD LV
20.0A
___________________
___________________
12 PMovl FIL=OFF
PMP OVL FILTER
OFF
___________________
___________________
13 Povl DLY=OFF
PMP OVERLOAD DLY
OFF
___________________
___________________
14 UNDERLOAD=N
N
___________________
___________________
15 ULD CUR=___A
UNDERLOAD CURREN
___A
___________________
___________________
16 ULD SPD=+100%
UNDERLOAD SPEED
+100%
___________________
___________________
17 ULD DELY=10s
UNDERLOAD DELAY
10s
___________________
___________________
18 DEC.SPdly=OFF
DECREM.SPD.DELAY
OFF
___________________
___________________
19 Sp.SRCH.I =10%
SPD.SEARCH INCR.
10%
___________________
___________________
G12: Auto Reset
1 AUTORESET=N
N
___________________
___________________
2 ATTEMP NUMBR=1
MAX ATTEMPT NUMB
1
___________________
___________________
3 R STR DEL=5s
TIME BEFORE RESET
5s
___________________
___________________
4 RS COUNT=15min
AUTORESET TIMOUT
15min
___________________
___________________
5 F1 AUTO RST=0
0
___________________
___________________
6 F2 AUTO RST=0
0
___________________
___________________
7 F3 AUTO RST=0
0
___________________
___________________
8 F4 AUTO RST=0
0
___________________
___________________
G13: Fault History
1 F0 NO FAULT
LAST FAULT=FXX
-
___________________
___________________
2 F0 NO FAULT
FIFTH FAULT=FXX
-
___________________
___________________
3 F0 NO FAULT
FOURTH FAULT=FXX
-
___________________
___________________
4 F0 NO FAULT
THIRD FAULT=FXX
-
___________________
___________________
5 F0 NO FAULT
SECOND FAULT=FXX
-
___________________
___________________
6 F0 NO FAULT
FIRST FAULT=FXX
-
___________________
___________________
7 CLEAR FAULTS=N
N
___________________
___________________
G14: Multi-references
1 MREF 1=+10.0%
MULTI-REFERENCE1
+10.0%
___________________
___________________
2 MREF 2=+20.0%
MULTI-REFERENCE2
+20.0%
___________________
___________________
3 MREF 3=+30.0%
MULTI-REFERENCE3
+30.0%
___________________
___________________
4 MREF 4=+40.0%
MULTI-REFERENCE4
+40.0%
___________________
___________________
5 MREF 5=+50.0%
MULTI-REFERENCE5
+50.0%
___________________
___________________
