Power Electronics SD700 User Manual

SD700FR SERIES
POWER ELECTRONICS
92
CONFIGURATION REGISTER
PARAMETERS
FACTORY SETTINGS
SETTING 1
SETTING 2
G9: Comparators – S9.3: Comparator 3
1 COMP 3 SEL=00
00
___________________
___________________
2 COM 3 TYPE=0
0
___________________
___________________
3 SP C3 ON=+100[%]
C3 ACTIVAT LEVEL
+100[%]
___________________
___________________
4 LIM 2 C3=+100[%]
C3 WINDOW LIMIT2
+100[%]
___________________
___________________
5 LIM 1 C3=+0[%]
C3 WINDOW LIMIT1
+0[%]
___________________
___________________
6 T C3 ON=0.0s
C3 ACTIVAT DELAY
0.0s
___________________
___________________
7 SP C3 OF=0[%]]
C3 DEACTIV LEVEL
+0[%]
___________________
___________________
8 T C3 OF=0.0s
C3 DEACTIV DELAY
0.0s
___________________
___________________
9 SEL FUNT C3=00
00
___________________
___________________
G10: Limits
1 MIN1 SP=+0.00%
SPEED MIN LIMIT1
+0.00%
___________________
___________________
2 MAX1 SP=+100%
SPEED MAX LIMIT1
+100%
___________________
___________________
3 MIN2 SP=-100%
SPEED MIN LIMIT2
-100%
___________________
___________________
4 MAX2 SP=+100%
SPEED MAX LIMIT2
+100%
___________________
___________________
5 I LIMIT=___A
MAX CURRENT
___A
___________________
___________________
6 I LIM TO = OFF
TIMOUT MAX CURRE
OFF
___________________
___________________
7 I. MAX2=____A
MAX CURRENT 2
___A
___________________
___________________
8 MI2 brSP=OFF
MAX CURR BRK SPD
OFF
___________________
___________________
9 MAX TOR=+150%
MAX TORQUE
+150%
___________________
___________________
10 T LIM TO=OFF
TIMEOUT MAX TORQ
OFF
___________________
___________________
11 INVERSION?=N
N
___________________
___________________
12 ILIM RGN=OFF
CURR.LIMIT.RGN
OFF
___________________
___________________
13 Ilim_rgnTO=OFF
ILim.Regen.Tmout
OFF
___________________
___________________
G11: Protections
1 SP LIM_TO=OFF
TMAX LIMITIN SPD
OFF
___________________
___________________
2 STOP TO=OFF
TIMEOUT STOPPING
OFF
___________________
___________________
3 GND I LIMIT=10%
GND CURR MAX LEV
10%
___________________
___________________
4 LOW VOLT=360V
LO INPUT VOLTAGE
360V
___________________
___________________
5 LOW V TO=5s
LO INP VOL TIMEO
5s
___________________
___________________
6 HIGH VOLT=500V
HI INPUT VOLTAGE
500V
___________________
___________________
7 HI V TO=5s
HI INP VOL TIMEO
5.0s
___________________
___________________
8 Dlasy VO = OFF
VOUT asyTRIP DLY
OFF
___________________
___________________
