Part 3 Mounting and Configuration
3.2 GRAPHICAL REPRESENTION OF THE CDD
Figure 3-1: Graphical Representation of References
Table 3-1: Reference Number Index
01
WiFi Antenna
06
Ethernet Port
02
Status LED
07
RJ45 Connector for RS485 Serial
03
RF Antenna
08
GoGo Relay Connector
04
Display
09
Power Supply Connector
05
Button Pad
10
Ethernet Communication Status LED
