Page 51 of 80 Instruction Manual for AURORA CDD BCG.00613_AA
Part 4 Operations Guide
The other option from the View drop-down
selection is
RF Signals
.
This selection will display a bar graph showing the radio signal strength for each inverter, and any
messages sent
.
* Each MICRO Inverter sends a package of data to the CDD once a minute.
Msg and Average plant signal index are refreshed every 15 minutes. In order to evaluate a CDD
positioning, 15 minutes have to pass from the power-on of the device.
strength from the
Messages received by the CDD
from each inverter in the last
RSSI is “received signal strength
indicator”, a measurement of the
power present in a received radio
signal from the MICRO inverter.
