50
K6 K8 K10 K20 | SERVICE MANUAL
INDEX
K - Series Mechanical parts “Outline vers.”
K_STD_HGT_No_ETH version
Part Number Description
SM00P917.3 Outline_T7_9_11_Front_Rear_side Rs 485 Vers.
SM00L489.3 K_STD_HGT_Platform Rs 485 Vers.
SM00P917.3 Outline_T7_9_11_Front_Rear_side Rs 485 Vers.
Part Number Qty Description
ME000211 1 Half rear panel
ME000317.2 1 Outline rear black panel x Rs 485 vers.
ME000284 2 K Series alluminium handle
ME000321 2 Front side gray plate
ME000322 2 Lateral plate
ML000016 2 EMI Spring
VI000112 1 Screw SCW|TBEI_|M3X6
SM00L489.3 K_STD_HGT_Platform Rs 485 Vers.
Part Number Qty Description
FI000021 2 Heatsink lter
ME000209 1 Cover
ME000216 1 Chassis Rev. 4
ME000235 8 Heatsink brass spacer
ME000258 1 Chassis lexan protection
ME000263 1 PSU lexan protection
ME000281 1 Mains connector plate
ML000016 8 EMI Spring
SC000005 1 Transparent bug
SC000061 1 Transparent bug
DS000010 2 Heatsink
ET000004 1 Ground label
VI000024 4 Screw SCW|TCEI_|M3X40
VI000031 4 Screw FWH|M3X9
VI000110 2 Spacer SPC|M3X37
