powersoft K Series User Manual

51
K6 K8 K10 K20 | SERVICE MANUAL
INDEX
K - Series Mechanical parts “Void vers.”
K - STD HGT No ETH version
Part Number Description
SM0F1059.3 VOID_Front_side
SM0P1059.3 VOID_V9_Front_Rear_side ETH Vers.
SM00L489.3 K_STD_HGT_Platform Rs 485 Vers.
SM00L489.3 K_STD_HGT_Platform Rs 485 Vers.
Part Number Qty Description
FI000021 2 Heatsink lter
ME000209 1 Cover
ME000216 1 Chassis Rev. 4
ME000235 8 Heatsink brass spacer
ME000258 1 Chassis lexan protection
ME000263 1 PSU lexan protection
ME000281 1 Mains connector plate
ML000016 8 EMI Spring
SC000005 1 Transparent bug
SC000061 1 Transparent bug
DS000010 2 Heatsink
ET000004 1 Ground label
VI000024 4 Screw SCW|TCEI_|M3X40
VI000031 4 Screw FWH|M3X9
VI000110 2 Spacer SPC|M3X37
