Specifications
65
Powerware
®
9125 User’s Guide (2500–3000 VA) : Rev B www.powerware.com
Table 7. Technical Specifications
Nominal Frequency 45–65 Hz, 50/60 Hz auto-sensing
Noise Filtering MOVs and line filter for normal and common mode noise
Regulation
(Normal mode)
Nominal output voltage ±3%
Regulation
(Battery mode)
Nominal output voltage ±3%
Voltage Waveform Normal mode: Sine wave; <5% THD with full PFC and nonlinear load
Table 8. Weights and Dimensions
UPS Extended Battery Module
Dimensions
(WxDxH)
17.0” x 23.9” x 3.5” (2U)
(43.2 x 60.7 x 8.9 cm)
17.0” x 23.9” x 3.5” (2U)
(43.2 x 60.7 x 8.9 cm)
Weight 81.5 lb (37 kg) 93 lb (42.5 kg)
Table 9. Battery
Configuration (6) 12V, 9 Ah internal batteries
EBM Configuration PW9125 72 EBM: (12) 12V, 9 Ah (2 strings of 6 batteries in parallel)
Type Sealed, maintenance-free, valve-regulated, lead-acid
Charging Internal battery: approximately 3 hours to 90% usable capacity at nominal line voltage after full
load discharge
External battery: no more than 20x discharge time to 90% usable capacity at nominal line
voltage after full load discharge
Monitoring Advanced monitoring for earlier failure detection and warning; auto detection of additional EBMs
Safety Conformance PW9125 72 EBM: UL 1778, UL 497A; CSA C22.2, No. 107.1, 107.2; IEC 60950; EN 50091-1-1
Agency Markings PW9125 72 EBM: UL, cUL, NOM-NYCE, CE, TUV-GS
Table 10. Battery Run Times (in Minutes at Full/Half Load)
Model Internal UPS
Batteries
1EBM 2EBMs 3EBMs 4EBMs
2500 VA/1750W 7/16 28/57 48/90 68/150 88/200
3000 VA/2100W 5/13 25/55 38/72 54/120 70/160
NOTE
Battery times are approximate and vary depending on the load configuration and battery charge.
