Additional UPS Features
54
Powerware
®
9125 User’s Guide (2500–3000 VA) : Rev B www.powerware.com
3. To prevent electrostatic discharge (ESD), place one hand on a
metal surface such as the UPS rear panel.
Align the single-port card with the slot guides and slide the
card into the slot until it is firmly seated.
4. Secure the single-port card with the screws removed in Step 1.
Network Transient Protector
The Network Transient Protector, shown in Figure 35, is located on the
rear panel and has jacks labeled IN and OUT. This feature
accommodates a single RJ-45 (10BaseT) network connector.
Low voltage models can also accommodate an RJ-11 telephone
connector that provides protection for modems, fax machines, or other
telecommunications equipment. As with most modem equipment, it is
not advisable to use this jack in digital PBX (Private Branch Exchange)
environments.
NOTE DO NOT connect any telephone or fax/modem equipment to the 230V models;
only network protection is available for 230V models.
1. Connect the input connector of the equipment you are
protecting to the jack labeled IN.
2. Connect the network or telephone cable (low voltage units
only) to the jack labeled OUT.
In
Out
Figure 35. Network Transient Protector
