47
Powerware
®
9125 User’s Guide (2500–3000 VA) : Rev B www.powerware.com
CHAPTER 5
CONFIGURATION
This section describes how to reconfigure options using the
Configuration mode, including: input voltage, site wiring fault, and AC
input alarm.
Configuration Mode
When the UPS is in Configuration mode, the bar graph indicators
represent the configuration options. The control buttons (On
button
and
button) are used to modify the UPS configuration. Figure 30
shows the LEDs and Table 2 explains the corresponding options.
NOTE The UPS can be configured while in Battery mode. If the UPS switches to
battery power while in Configuration mode, the UPS remains in Configuration mode
and indicates Battery mode on the front panel.
CAUTION
DO NOT press the Off button while the UPS is in Configuration mode; pressing the
Off
button removes all power to your equipment immediately and the UPS enters
Standby mode.
1. Press the On button and the button simultaneously for
one beep. The UPS switches to Configuration mode.
The bar graph indicators flash briefly and then display the
enabled options.
2. Press the On
button to scroll through the options. Each time
you press the button, the UPS beeps. The LED for the selected
option indicates the current setting; flashing represents disabled
options (see Figure 30 and Table 2).
If you press the On
button and nothing happens, the UPS is
still in Operation mode. Repeat Step 1 for one beep ONLY to
enter Configuration mode, and then perform Step 2.
