AR Standard Repeater PCBA Connections
2-8 044-05250 Rev B
FOU
FOU connections depend on the repeater type and if the FOU is connected to the donor or
service side. The RF connections for the FOU and the DPX used on the RF side are
illustrated in Figure 2-6 and listed in Table 2-10.
HI CSel GSM repeater: 4 channels: Output on the CMB/DL
2 channels: P701 on the CHE1/DL
CSel CDMA/WCDMA and BSel repeaters: P5 on the PA/DL
High power CDMA/WCDMA repeater: P4 on the BA/DL PCBA in
the cover
LO IN on the LNA/UL
P2101 on the WBA PCBA
Donor DPX Port Connected to
ANT FOR: ANT on the FOU/DPX filter.
All other types: DPX on the donor (BS) DC
HI IN on the LNA/DL
LO CSel GSM repeater: 4 channels: Output on the CMB/UL
2 channels: P701 on the CHE3/UL
CSel CDMA/WCDMA, High power CDMA/WCDMA and BSel
repeaters: P5 on the PA/UL
