AR Standard Repeater Mounting
044-05250 Rev B 3-3
Figure 3-3 illustrates the installation of the mounting bracket on a pole using two 5.7”
(144mm) U-shaped clamps and a locking screw.
Figure 3-3 Attaching the bracket to a pole
Figure 3-4 illustrates a mast installation using two 11.8” (300mm) bar-shaped clamps and no
locking screw.
Figure 3-4 Attaching the bracket to a mast
