044-05250 Rev B 5-1
Chapter 5
Specifications
Introduction
This chapter provides specifications for the AR Standard Repeater product line.
Table 5-1 AR Standard Repeater Specifications
Generic
Dimensions (W x H x D in inches) 17.5 x 21 x 7 (low cover)
17.5 x 21 x 11 (high cover)
Weights:
Empty low cover
Repeater with a low cover
Combined repeater with a high cover
Equipped cabinet or high cover w/extra heat sink element
13 lbs (6.0 kg)
50 lbs (22.5 kg)
82 lbs (37.0 kg)
41 lbs (18.5 kg)
Temperature range -13 to +131°F (-25 to + 55°C)
Casing class NEMA4/IP65
Fiber Optic Link Budget 15dBo
Amplifiers in 1 cabinet Standard = 2; High Power = 4
Receiver input port return loss 14dB
Power supply voltage (default) 115 VAC
Power consumption, max 160 W
AR1200 Family - GSM 900 Band Selective
Frequency band UL 890-915 MHz
Frequency band DL 935-960 MHz
Number of channels N/A
Absolute group delay 6 µs
Filter bandwidth (remotely adjustable) 0.5-16.9 MHz, remote adjustable
Gain adjustment range (in 1 dB steps) 45-85dB
Gain (max variation –25 to +55 °C) 6dB
Pass band ripple 4dB
Maximum input power (non-destructive) +13dBm
Output power RMS, one carrier, DL +26dBm (+29dBm PEP)
Noise figure at 85 dB gain, 25° C (typical) 6dB
