Introduction AR Standard Repeater
5-2 044-05250 Rev B
AR1700 Family - GSM 900 Channel Selective
Frequency band UL 890-915 MHz
Frequency band DL 935-960 MHz
Number of channels 1 to 8
Absolute group delay 5 µs
Filter bandwidth (remotely adjustable) 200 KHz
Gain adjustment range (in 1 dB steps) 55-90dB
Gain (max variation –25 to +55 °C) 4dB
Pass band ripple 3dB
Maximum input power (non-destructive) +13dBm
Output power RMS, one carrier, DL +33dBm
Noise figure at 85 dB gain, 25° C (typical) 4dB
AR2100/2700 Family - GSM 1800 Channel Selective
Frequency band UL 1710-1785 MHz
Frequency band DL 1805-1880 MHz
Number of channels 1 to 8
Absolute group delay 5 µs
Filter bandwidth (remotely adjustable) 200 KHz
Gain adjustment range (in 1 dB steps) 55-90dB
Gain (max variation –25 to +55 °C) 4dB
Pass band ripple 3dB
Maximum input power (non-destructive) +13dBm
Output power RMS, one carrier, DL +32dBm
Noise figure at 85 dB gain, 25° C (typical) 4dB
AR2200 Family - GSM 1800 Band Selective
Frequency band UL 1710-1785 MHz
Frequency band DL 180-1880 MHz
Number of channels N/A
Absolute group delay 6 µs
Filter bandwidth (remotely adjustable) 0.5-16.9 MHz, remotely adjustable
Gain adjustment range (in 1 dB steps) 45-85dB
