AR Standard Repeater Introduction
044-05250 Rev B 5-3
Gain (max variation –25 to +55 °C) 6dB
Pass band ripple 5dB
Maximum input power (non-destructive) +13dBm
Output power RMS, one carrier, DL +29dBm (+32dBm PEP)
Noise figure at 85 dB gain, 25° C (typical) 6dB
AR3100/3700 Family - GSM 1900 Channel Selective
Frequency band UL 1850-1910 MHz
Frequency band DL 1930-1990 MHz
Number of channels 1 to 8
Absolute group delay 5 µs
Filter bandwidth (remotely adjustable) 200 KHz
Gain adjustment range (in 1 dB steps) 55-90dB
Gain (max variation –25 to +55 °C) 4dB
Pass band ripple 3dB
Maximum input power (non-destructive) +13dBm
Output power RMS, one carrier, DL +32dBm
Noise figure at 85 dB gain, 25° C (typical) 4dB
AR3400 Family - GSM 1900 Band Selective
Frequency band UL 1710-1785 MHz
Frequency band DL 1805-1880 MHz
Number of channels N/A
Absolute group delay 6 µs
Filter bandwidth (remotely adjustable) 0.5-16.8 MHz, remotely adjustable
Gain adjustment range (in 1 dB steps) 45-85dB
Gain (max variation –25 to +55 °C) 6dB
Pass band ripple 5dB
Maximum input power (non-destructive) +13dBm
Output power RMS, one carrier, DL +33dBm (+36dBm PEP)
Noise figure at 85 dB gain, 25° C (typical) 6dB
