Introduction AR Standard Repeater
5-4 044-05250 Rev B
AR1700/902 Family - EGSM 900 Channel Selective
Frequency band UL 880-915 MHz
Frequency band DL 925-960 MHz
Number of channels 1 to 8
Absolute group delay <5 µs
Gain adjustment range (in 1 dB steps) 55-90dB
Gain (max variation –25 to +55 °C) 4dB
Pass band ripple 1dB
Maximum input power (non-destructive) +13dBm
Output power RMS, one carrier, DL +33dBm
Noise figure at 85 dB gain, 25° C (typical) 4dB
AR1100/802 Family - RGSM 900 Channel Selective
Frequency band UL 876-880 MHz
Frequency band DL 921-925 MHz
Number of channels 1 to 4
Absolute group delay <5 µs
Gain adjustment range (in 1 dB steps) 55-90dB
Gain (max variation –25 to +55 °C) 4dB
Pass band ripple 1dB
Maximum input power (non-destructive) +13dBm
Output power RMS, one carrier, DL +33dBm
Noise figure at 85 dB gain, 25° C (typical) 4dB
AR6500 Family - WCDMA Channel Selective
Frequency band UL 1920-1980 MHz
Frequency band DL 2110-2170 MHz
Number of channels 1 to 2
Absolute group delay 6 µs
Filter bandwidth (remotely adjustable) 5 MHz
Gain adjustment range (in 1 dB steps) 60-90dB
Gain (max variation –25 to +55 °C) 4dB
Pass band ripple 2dB within 4 MHz
