AR Standard Repeater Introduction
044-05250 Rev B 5-5
Maximum input power (non-destructive) +13dBm
Output power RMS, one carrier, DL +30dBm; Standard AR6500
Output power RMS, one carrier, UL +20dBm
Output power RMS, one carrier, DL +38dBm; High Power AR6560
Noise figure at 85 dB gain, 25° C (typical) 3dB
AR3400 Family – TDMA/CDMA Band Selective
Frequency band UL 1850-1910 MHz
Frequency band DL 1930-1990 MHz
Absolute group delay 6 µs
Filter bandwidth (remotely adjustable) 0.5-16.9 MHz
Gain adjustment range (in 1 dB steps) 45-85dB
Gain (max variation –25 to +55 °C) 6dB
Pass band ripple 5dB
Maximum input power (non-destructive) +13dBm
Output power RMS, one carrier, DL +33dBm (+36dBm PEP)
Output power RMS, one carrier, UL +33dBm (+36dBm PEP)
Output power RMS, one carrier, DL +36dBm (+39dBm PEP) AR4240
Noise figure at 85 dB gain, 25° C (typical) 6dB
AR4200 Family – AMPS Band Selective
Frequency band UL 824-849 MHz
Frequency band DL 869-894 MHz
Absolute group delay 6 µs
Filter bandwidth (remotely adjustable) 0.5-16.9 MHz
Gain adjustment range (in 1 dB steps) 45-85dB
Gain (max variation –25 to +55 °C) 6dB
Pass band ripple 5dB
Maximum input power (non-destructive) +13dBm
Output power RMS, one carrier, DL +33dBm (+36dBm PEP) AR4200
Output power RMS, one carrier, UL +33dBm (+36dBm PEP)
Output power RMS, two carrier, DL +36dBm (+39dBm PEP) AR4240
Noise figure at 85 dB gain, 25° C (typical) 6dB
