Introduction AR Standard Repeater
5-6 044-05250 Rev B
AR4600 Family – iDEN/SMR Band Selective
Frequency band UL 806-824 MHz
Frequency band DL 851-869 MHz
Absolute group delay 6 µs
Filter bandwidth (remotely adjustable) 0.5-16.9 MHz
Gain adjustment range (in 1 dB steps) 45-85dB
Gain (max variation –25 to +55 °C) 6dB
Pass band ripple 5dB
Maximum input power (non-destructive) +13dBm
Output power RMS, one carrier, DL +33dBm (+36dBm PEP) AR4200
Output power RMS, one carrier, UL +33dBm (+36dBm PEP)
Output power RMS, two carrier, DL +36dBm (+39dBm PEP) AR4240
Noise figure at 85 dB gain, 25° C (typical) 6dB
