Powtran PI160 Series User Manual

Chapter 5 Function parameter
66
Chapter 5
arrival
reaches the upper limit frequency.
18
Lower limit frequency
arrival (Shutdown
without output)
Outputs ON signal when the operating frequency
reaches the lower limit frequency Outputs OFF signal
when the inverter is in the state of stop
19
Undervoltage status
output
Outputs ON signal when the inverter is in the
undervoltage condition
20
Communication setting
Please refer to communication protocol.
23
Zero speed running 2
(Shutdown with output)
Outputs ON signal when the inverter output frequency
is 0. Outputs ON signal too when the inverter is in the
state of stop
24
Accumulated power-
on time arrival
Outputs ON signal when the inverter's accumulated
power-on time(F6.08) exceeds the set time by F7.20.
25
Frequency level
detection FDT2 output
Please refer to the instructions of function code F7.26,
F7.27
26
Frequency 1 reaches
output value
Please refer to the instructions of function code F7.28,
F7.29
27
Frequency 2 reaches
output value
Please refer to the instructions of function code F7.30,
F7.31.
28
Current 1 reaches
output value
Please refer to the instructions of function code
F7.36., F7.37
29
Current 2 reaches
output value
Please refer to the instructions of function code F7.38,
F7.39
30
Timer reaches output
value
Outputs ON signal when timer(F7.42)is active and
after the inverter's current running time reaches the set
time.
31
AI1 input exceed limit
Outputs ON signal when the analog input
AI1 value is greater than F7.51 (AI1 input protection
upper limit) or less than F7.50 (AI1 input protection
limit)
32
Load droping
Outputs ON signal when the inverter is in the load
drop status.
33
Reverse running
Outputs ON signal when the inverter is in the reverse
running status.
34
Zero current status
Please refer to the instructions of function code F7.32,
F7.33
35
Module temperature
arrival
Outputs ON signal when the inverter
module radiator temperature (F6.06) reaches the set
temperature(F7.40).
36
Software current
overrun
Please refer to the instructions of function code F7.34,
F7.35
37
Lower limit frequency
arrival(Stop with output)
Outputs ON signal when the operating frequency
reaches the lower limit frequency Outputs ON signal
too when the inverter is in the sate of stop
38
Alarm output
When the inverter occurs failure and
continues to run, the inverter alarms output.
40
Current running time
arrival
Outputs ON signal when the inverter's current running
time exceeds the set time by F7.45.
41
Break fault
When inverter stop running because of break fault, it
outputs active signal
42
High frequency output
When the output frequency larger than the closed set
frequency of relay, it outputs active signal
F2.
07
DA1 output function selection
0
～17
2
☆
Analog output DA1 output range is 0V to 10V, or 0mA to 20mA. The range of pulse output
