PR 9116 - Detailed Specifications; Accuracy Details; EMC Immunity; Auxiliary Supplies and Physical Data

9116 - Product Version 9116-003 9
Auxiliary supplies for 9116B1:
2-wire supply (terminal 54...52) ........................ 28...16.5 VDC / 0...20 mA
Auxiliary supplies for 9116B2:
2-wire supply (terminal 54...52) ........................ 22...16.5 VDC / 0...20 mA
Wire size (max....min.) ............................................. AWG 26...14 / 0.13...2.08 mm
2
stranded wire
Screw terminal torque ........................................... 0.5 Nm
Relative humidity.....................................................  <95%RH(non-cond.)
Dimen., without display front (HxWxD) .......... 109 x 23.5 x 104 mm
Dimensions, with display front (HxWxD) ....... 109 x 23.5 x 116 mm
Protection degree .................................................... IP20
Weight .......................................................................... 185 g / 200 g with 4501
EMC immunity influence .................................................. <±0.5%ofspan
Extended EMC immunity:
NAMUR NE 21, A criterion, burst ................................. <±1%ofspan
Basic values
Input
type
Basic
accuracy
Temperature
coefficient
mA ≤ ±16 µA ≤ ±1.6 µA / °C
Volt ≤ ±20 µV ≤ ±2 µV / °C
Pt100, Pt200,
Pt 1000 ≤ ±0.2°C ≤ ±0.02°C / °C
Pt500, Ni100,
Ni120, Ni 1000 ≤ ±0.3°C ≤ ±0.03°C / °C
Pt50, Pt400, Ni50 ≤ ±0.4°C ≤ ±0.04°C / °C
Pt250, Pt300 ≤ ±0.6°C ≤ ±0.06°C / °C
Pt20 ≤ ±0.8°C ≤ ±0.08°C / °C
Pt10 ≤ ±1.4°C ≤ ±0.14°C / °C
TC type:
E,J,K,L,N,T,U ≤ ±1°C ≤ ±0.1°C / °C
TC type: R, S, W3,
W5, LR ≤ ±2°C ≤ ±0.2°C / °C
TC type: B
160...400°C ≤ ±4.5°C ≤ ±0.45°C / °C
TC type: B
400...1820°C ≤ ±2°C ≤ ±0.2°C / °C
