PR 9116 - Hardware Error Diagnostics; Hardware Error Codes and Causes

14 9116 - Product Version 9116-003
Hardware error
Readout at hardware error
Error search Readout Cause
CJCsensorerror-checkdevicetemperature CJ.ER
DefectinternalCJCsensoror
CJCtemperatureoutofallowed
range **
CJCconnectorerror-checkCJCconnectorblock CJ.CE
Defect(ormissing)CJCconnector
or temperature out of allowed
range **
Input error - check input connection and reset power IN.ER
Signal levels on input beyond
limits or connected to wrong
terminals*
Output error - check output connections and reset
power
AO.ER
Error in analogue output current
(SIL mode only)*
No communication NO.CO
No communication
with (4501)
Flash memory error - check configuration
FL.ER
CO.ER
FLASH error
(configuration invalid)***
Invalid configuration type or version TY.ER
Configuration read from EEprom
has invalid type or rev. no.
Hardware error RA.ER RAM error*
Hardware error IF.ER Internal Flash error*
Hardware error SW.ER SW monitor error*
Hardware error AD.ER A/D converter error*
Hardware error AO.SU
Analogue output
supply error*
Hardware error CA.ER Factory calibration error*
Hardware error CM.ER Main CPU error*
Hardware error RE.ER Relay readback error*
Hardware error II.ER Initialization check error*
Hardware error RS.ER Reset error*
Hardware error IC.ER Input communication error*
Hardware error M1.ER Main CPU to Ch.1 error*
Hardware error MC.ER Main CPU config. error*
Hardware error MF.ER Main CPU Flash error*
Hardware error MR.ER Main CPU Ram error*
Hardware error MS.ER Main CPU supply error*
Hardware error MP.ER Main CPU ProgFlow error*
Hardware error MI.ER
Main CPU initialization
check error*
Hardware error DE.ER Device error*
Hardware error FC.ER Invalid code checksum in 4501
