13.3.7 Simulation (SIM)
It is possible to override the actual measured input signal by a simulated
value. In the REL.SIM menu it is posible to simulate the relay state with out
affecting the analogue output, by pressing
1 . Leaving the simulation menus,
or disconnecting the 4501 device, will disable the simulation mode and bring
the output back to correspond to the actual measured value. Simulation is
not possible in SIL-mode.
13.3.8 Safety integrity level (SIL)
See section 14 - Safe parameterisation - user responsibility
14 Safe parameterisation - user responsibility
14.1 Safety-related configuration parameters
14.1.1 Common parameters
Name Function
IN.TYPE Selected input type:
TEMP = Temperature
CURR = Current
VOLT = Voltage
LIN.R = Linear resistance
POTM = Potentiometer
I.RANGE Selected fixed input range for current measurements (for
IN.TYPE = CURR):
0_20 = 0...20 mA (no sensor error detection!)
4_20 = 4...20 mA
V.RANGE Selected fixed input range for voltage measurements
(for IN.TYPE = VOLT)
SENSOR Selected temperature sensor type (for IN.TYPE = TEMP):
TC = Thermocouple
Ni = Ni RTD sensor
Pt = Pt RTD sensor
