PR 9116 - Parameter Details: Sensor Types; Pt Sensor Type Selection; Ni Sensor Type Selection; TC Sensor Type and CJC Options

12 Version No. V3R0
Safety Manual 9116 UNIVERSAL CONVERTER
Pt.TYPE Pt sensor type (for SENSOR = Pt):
10 = Pt10
20 = Pt20 (No short circuit detection!)
50 = Pt50
100 = Pt100
200 = Pt200
250 = Pt250
300 = Pt300
400 = Pt400
500 = Pt500
1000 = Pt1000
Ni.TYPE Ni sensor type (for SENSOR = Ni):
50 = Ni50
100 = Ni100
120 = Ni120
1000 = Ni1000
TC.TYPE Thermocouple type (for SENSOR = TC):
TC.B = Thermocuple type B
TC.E = Thermocuple type E
TC.J = Thermocuple type J
TC.K = Thermocuple type K
TC.L = Thermocuple type L
TC.N = Thermocuple type N
TC.R = Thermocuple type R
TC.S = Thermocuple type S
TC.T = Thermocuple type T
TC.U = Thermocuple type U
TC.W3 = Thermocuple type W3
TC.W5 = Thermocuple type W5
TC.Lr = Thermocuple type Lr
CJC CJC type for SENSOR = TC:
INT = Internal CJC sensor measurement
CONN = CJC connector measurement (accessory)
}
