PR 9116 - Error Indications (Without Display Front); LED and Error Signal Status

18 9116 - Product Version 9116-003
Signal error and cable fault indications without display front
List of LED and error signal indications
Condition Green LED
Relay:
Yellow LED
Error:
Red LED
Status relay,
N.C.
Power rail
signal status
No supply OFF OFF OFF De-energized Closed
Device failure OFF ON De-energized Closed
Device OK Flashing Energized Open
Signal OK Flashing OFF Energized Open
Output relay energized Flashing ON OFF Energized Open
Output relay energized
w. wire short/break
Flashing ON Flashing De-energized
Closed (if enab-
led)
Output relay de-energized
w. wire short/break
Flashing OFF Flashing De-energized
Closed (if enab-
led)
Output relay de-energized Flashing OFF OFF Energized Open
