9116 UNIVERSAL CONVERTER Safety Manual
14.2.1 If no password is set
Action Display shows
1 Press OK ADV.SET
2 Set (ADV.SET) to Yes and press OK SETUP
3 Set SETUP to SIL and press OK EN.SIL
4 Set EN.SIL to YES and press OK NEW.PAS
5 Set password to a number between 0 and
9999 and press OK
(At this time the device starts operating
in SIL mode with the entered configuration
parameters!)
CONFIG
Verify
OPEN->LOCK
(Note
7
)
6 Press OK to confirm verification of the OPEN-
>LOCK in the display
IN.TYPE
7 Verify input type and press OK I.RANGE
8 Verify fixed input current range and press OK
(ONLY if IN.TYPE = CURR)
CONNEC
9 Verify sensor connection type and press OK
(ONLY if IN.TYPE = TEMP and SENSOR = Ni or Pt
or IN.TYPE = LIN.R)
UNIT
10 Verify temperature unit and press OK
(ONLY if IN.TYPE = TEMP)
SENSOR
11 Verify temperature sensor type and press OK
( ONLY if IN.TYPE = TEMP)
Pt.TYPE
12 Verify Pt sensor type and press OK
(ONLY if IN.TYPE = TEMP and SENSOR = Pt)
Ni.TYPE
13 Verify Ni sensor type and press OK
(ONLY if IN.TYPE = TEMP and SENSOR = Ni)
TC.TYPE
14 Verify Thermocouple type and press OK
(ONLY if IN.TYPE = TEMP and SENSOR = TC)
CJC
Note
7
: Open is shown briefly in the display.
