8 9116 - Product Version 9116-003
Electrical specifications
Specifications range ............................................... -20°C to +60°C
Storage temperature .............................................. -20°C to +85°C
Common specifications:
Supply voltage, DC .................................................. 19.2...31.2 VDC
Max. consumption .................................................... ≤ 3.5 W
Fuse ............................................................................... 1.25 A SB / 250 VAC
Isolation - test / working:
Input to any ...................................................... 2.6 kVAC / 300 VAC reinforced
Analogue output to supply ........................ 2.6 kVAC / 300 VAC reinforced
Status relay to supply .................................. 1.5 kVAC / 150 VAC reinforced
Communications interface ................................... Programming front 4501
Signal / noise ratio .................................................. Min. 60 dB (0...100 kHz)
Response time (0...90%, 100...10%):
Temperature input, programmable .......... 1...60 s
mA / V input, programmable ...................... 0.4...60 s
Calibration temperature ........................................ 20...28°C
Accuracy, the greater of the general and basic values:
General values
Input
type
Absolute
accuracy
Temperature
coefficient
All ≤ ±0.1% of span ≤ ±0.01% of span / °C
4501 = Display / programming front
4511 = Modbus communication enabler
5910Ex = CJC connector
9400 = Power rail
9404 = Module stop for rail
9410 = Power control unit
9420 = Power supply 24 V / 120 W - Ex nAC
Accessories
Type Max. loop voltage
9116
Uo 28 VDC : 1
Uo 22 VDC : 2
Ordering codes for 9116B
