PR 9116 - Relay Output Parameter Configuration; Relay Units and Functions; Relay Setpoint and Action Parameters

14 Version No. V3R0
Safety Manual 9116 UNIVERSAL CONVERTER
14.1.2 Parameters related to Relay Output
REL.UNI Relay Units (for IN.TYPE ≠ TEMP):
PERC = Relay setpoint in percent of input range.
DISP = Relay setpoints and hysteresis values relates to DISP.LO
and DISP.HI (display units)
REL.FUN Relay Function:
OFF (Note
3
) = Relay is always OFF
POW (Note
3
) = Relay is always ON if power is applied
ERR = Relay is activated when sensor error is present
WIND = Relay is activated when input signal is between SETP.
LO and SETP.HI values
SETP = Relay is activated when input signal reaches SETP
value
CONTAC. Relay contact function:
N.C. = Normaly Closed relay contact (for REL.FUN = SETP)
N.O. = Normally Open relay contact (for REL.FUN = SETP)
O.I.W = Relay contact Open Inside Window (for REL.FUN =
WIND)
C.I.W = Relay contact Closed Inside Window (for REL.FUN =
WIND)
SETP. Relay setpoint value in REL.UNI units for IN.TYPE ≠ TEMP or
in UNIT for IN.TYPE = TEMP. (for REL.FUN = SETP)
SETP.LO Relay setpoint low value in REL.UNI units for IN.TYPE ≠ TEMP
or in UNIT for IN.TYPE = TEMP. (for REL.FUN = WIND)
SETP.HI Relay setpoint high value in REL.UNI units for IN.TYPE ≠ TEMP
or in UNIT for IN.TYPE = TEMP. (for REL.FUN = WIND)
ACT.DIR Relay action for increasing or decreasing input signal
(for REL.FUN = SETP):
DECR = Relay activates when input signal ≤ SETP.
INCR = Relay activates when input signal ≥ SETP.
HYST Hysteresis value in REL.UNI units for IN.TYPE ≠ TEMP or in
UNIT for IN.TYPE = TEMP. (for REL.FUN = SETP or WIND)
