PR 9116 - Verification Procedure (Continued); Temperature and Unit Verification; Relay Settings Verification

18 Version No. V3R0
Safety Manual 9116 UNIVERSAL CONVERTER
Action Display shows
15 Verify CJC type and press OK
(ONLY if IN.TYPE = TEMP and SENSOR = TC)
V.RANGE
16 Verify fixed input voltage range and press OK
(ONLY if IN.TYPE = VOLT)
R 0%
17 Verify input resistance 0% range and press OK
(ONLY if IN.TYPE = LIN.R)
R 100%
18 Verify input resistance 100% range and press OK
(ONLY if IN.TYPE = LIN.R)
UNIT
19 Verify display units for 4501 and press OK
(ONLY if IN.TYPE ≠ TEMP)
DEC.P
20 Verify display decimal point for 4501 and press OK
(ONLY if IN.TYPE ≠ TEMP)
DISP.LO
21 Verify display value for 4501 at 0% input and
press OK
(ONLY if IN.TYPE ≠ TEMP)
DISP.HI
22 Verify display value for 4501 at 100% input and
press OK
(ONLY if IN.TYPE ≠ TEMP)
REL.UNI
23 Verify relay setpoint units and press OK
(ONLY if IN.TYPE ≠ TEMP)
REL.FUN
24 Verify relay function and press OK CONTAC.
25 Verify relay contact function and press OK
(ONLY if REL.FUN ≠ OFF or POW)
SETP.
26 Verify relay setpoint and press OK
(ONLY if REL.FUN = SETP)
SETP.LO
27 Verify low setpoint value and press OK
(ONLY if REL.FUN = WIND)
SETP.HI
28 Verify high setpoint value and press OK
(ONLY if REL.FUN = WIND)
ACT.DIR
