PR 9116 - Verification Procedure (Final Steps); Relay and Output Verification; Password and SIL Mode Verification

Version No. V3R0 19
9116 UNIVERSAL CONVERTER Safety Manual
Action Display shows
29 Verify relay activation direction and press OK
(ONLY if REL.FUN = SETP)
HYST
30 Verify relay setpoint hysteresis and press OK
(ONLY if REL.FUN = SETP or WIND)
ERR.ACT
31 Verify relay action on sensor error and press OK
(ONLY if REL.FUN = SETP, WIND or ERR and the
selected input type and range support sensor error
detection, refer to section 4.3.2)
ON.DEL
32 Verify relay ON delay and press OK
(ONLY if REL.FUN = SETP or WIND)
OFF.DEL
33 Verify relay OFF delay and press OK
(ONLY if REL.FUN = SETP or WIND)
O.RANGE
34 Verify fixed output range for current output OUT.ERR
35 Verify fixed output value on detected sensor error
and press OK
(ONLY if IN.TYPE ≠ VOLT, or IN.TYPE = CURR and
I.RANGE ≠ 0-20 mA)
OUT.LO
36 Verify temperature for 0% output and press OK
(ONLY if IN.TYPE = TEMP)
OUT.HI
37 Verify temperature for 100% output and press OK
(ONLY if IN.TYPE = TEMP)
RESP
38 Verify analogue output response time and press OK CH1.CAL
39 Verify the use of applied process calibration values
and press OK
PASSW.
40 Verify password and press OK SIL.OK
41 Verify SIL mode within 1 second
