LERBAKKEN 10, 8410 ROENDE DENMARK
Revision date:
2012-06-08
Version Revision
V6 R0
Prepared by:
PB
Page:
2/4
Terminal 51-52, 51-53 Terminal 51-52, 51-53
Ui, Vmax 30 V Ui, Vmax 30 V
Ii, Imax 120 mA Ii, Imax 120 mA
Pi 900 mW Pi 900 mW
Ci 3 nF Ci 3 nF
Li 1 μH Li 1 μH
Uo, Voc 28 V
IIC or A,B
80 nF 4 mH 54 μH/Ω Uo, Voc 21.4 V
IIC or A,B
0.16 μF 4 mH 54 μH/Ω
Io, Isc 93 mA
IIB or C,E,F
640 nF 16 mH 218 μH/Ω Io, Isc 93 mA
IIB or C,E,F
1.13 μF 16 mH 218 μH/Ω
Po 650 mW
IIA or D,G
2.1 μF 32 mH 436 μH/Ω Po 650 mW
IIA or D,G
4.15 μF 32 mH 436 μH/Ω
Uo, Voc 28 V
IIC or A,B
80 nF 1000 mH 4 mH/Ω Uo, Voc 21.4 V
IIC or A,B
0.16 μF 1000 mH 4 mH/Ω
Io, Isc 1.1 mA
IIB or C,E,F
640 nF 1000 mH 17 mH/Ω Io, Isc 1.1 mA
IIB or C,E,F
1.13 μF 1000 mH 17 mH/Ω
Po 8 mW
IIA or D,G
2.1 μF 1000 mH 35 mH/Ω Po 8 mW
IIA or D,G
4.15 μF 1000 mH 35 mH/Ω
Uo, Voc 8.3 V
IIC or A,B
7 μF 1000 mH 100 mH/Ω Uo, Voc 8.3 V
IIC or A,B
7 μF 1000 mH 100 mH/Ω
Io, Isc 0.2 mA
IIB or C,E,F
73 μF 1000 mH 400 mH/Ω Io, Isc 0.2 mA
IIB or C,E,F
73 μF 1000 mH 400 mH/Ω
Po 0.4 mW
IIA or D,G
1000 μF 1000 mH 800 mH/Ω Po 0.4 mW
IIA or D,G
1000 μF 1000 mH 800 mH/Ω
Uo, Voc 8.3 V
IIC or A,B
7 μF 207 mH 1 mH/Ω Uo, Voc 8.3 V
IIC or A,B
7 μF 207 mH 1 mH/Ω
Io, Isc 13.1 mA
IIB or C,E,F
73 μF 828 mH 5 mH/Ω Io, Isc 13.1 mA
IIB or C,E,F
73 μF 828 mH 5 mH/Ω
Po 27.3 mW
IIA or D,G
1000 μF 1000 mH 10 mH/Ω Po 27.3 mW
IIA or D,G
1000 μF 1000 mH 10 mH/Ω
Co Lo Lo/Ro
Module 9116B1
Terminal 41,42,43,44
Group Co Group
Co Lo Lo/Ro
Module 9116B1
Terminal 51-52
Group Co Lo Lo/Ro
Module 9116B2
Terminal 51-52
Group
Co Lo Lo/Ro
Module 9116B1
Terminal 51-53
Group Co Lo Lo/Ro
Module 9116B2
Terminal 51-53
Group
Module 9116B1 Module 9116B2
Module 9116B1
Terminal 51-54, 52-54
Group Co Lo Lo/Ro
Module 9116B2
Terminal 51-54, 52-54
Group
Lo Lo/Ro
Module 9116B2
Terminal 41,42,43,44
Co Lo Lo/Ro
Installation notes:
The installation and wiring shall be in accordance with the Canadian Electrical Code for Canada and
National Electrical Code NFPA 70, Article 500 or 505 for installation in USA.
The module must be supplied from a Power Supply having double or reinforced insulation.
The use of stranded wires is not permitted for mains wiring except when wires are fitted with cable ends.
For installation on the 9400 Power Rail the power must be supplied from Power Control Module Unit 9410.
Install in pollution degree 2 or better, overvoltage category I or II.
The module must be installed in an enclosure suitable for the environment for which it is used.
In Class I, Division 2 /Zone 2 installations, the subject equipment shall be mounted within a tool-secured
enclosure which is capable of accepting one or more of the Class I, Division 2 wiring methods specified in
the National Electrical Code for USA or the Canadian Electrical Code for Canada
The module is galvanic isolated and does not require grounding.
Use 60 / 75 ºC Copper Conductors with wire Size AWG: (26-14).
Warning: Substitution of components may impair intrinsic safety.
Warning: To prevent ignition of the explosive atmospheres, disconnect power before servicing and do not
separate connectors when energized and an explosive gas mixture is present.
Warning: Do not mount or remove modules from the Power Rail when an explosive gas mixture is present.
