C842, C842i, C846, C846i Upright and Recumbent Cycle
Page 51
22. Remove the plate that covers the hand held heart rate cable on the bottom of the seat. See
Diagram 7.11. The cable may be stuck to the plate with double sided tape.
Diagram 7.11 - Seat Bottom
23. Disconnect the external hand held heart rate cable from the internal hand held heart rate
cable.
24. If only the external cable is being replaced, skip to step 29. If the internal cable is being
replaced continue with step 25.
25. Remove the screws retaining the hand held heart rate contact plates from both the left and
right seat handlebars. Disconnect the cable from all four hand held heart rate contact plates.
Draw the internal cable out of the bottom of the seat.
26. feed the replacement internal hand held heart rate cable into the seat. The cable with the
blue tape will feed into the right handlebar and the cable with the black tape will feed into the
left handlebar. See Diagram 7.12.
