Precor C842 User Manual

C842, C842i, C846, C846i Upright and Recumbent Cycle
Page 53
Procedure 7.5 - Replacing the Column
1. For C842, C846i and C846 version 2 units, skip to step 14. For C846 version 1 units,
continue with step 2.
2. Set the on/off switch in the off position.
3. Remove the left hand cover per Procedure 7.1.
4. Remove the display housing per Procedure 7.12, steps 1-4.
5. Disconnect the upper interconnect cable from the junction block located near the base of the
column (see Diagram 7.13).
Diagram 7.13 - Interconnect Cable Junction Blocks
6. Remove the four bolts from the base of the column and remove the column.
7. Carefully remove the upper interconnect cable from the column.
8. Insert the upper interconnect cable into the replacement column. The interconnect cable
must protrude form the upper end of the column and the lower access hole.
Junction Block
Lower
Interconnect Cable
Upper Interconnect Cable
