Belt Drive Tension Adjustment
About
This procedure provides instruction to verify and make adjustments to the belt drive tension.
The belt tension should be verified anytime the belt is replaced, at regularly scheduled pre-
ventative maintenance, or when there are any unusual belt related issues (noises, pedal slip,
etc.) while operating the bike.
Belt adjustment requires removing the front and rear belt guards and the use of a belt tension
gauge.
CAUTION: Improper belt adjustment will cause premature wear and may void the
Precor Limited Warranty.
Specifications
System Component Specification
Belt Drive Tension 140 - 150 lbs
Available Movies
(Internet Only)
Belt Tension Adjustment
Procedure
Review entire procedure before starting.
1. Remove front and rear belt guards, see "Belt/Chain Guard Cover Replacement" on
page19.
2. Remove all brake pad flywheel resistance by turning the resistance knob coun-
terclockwise (-).
3.
Place the Belt Tension Gage onto the belt .
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 10
4 Adjustment Procedures
Belt Drive Tension Adjustment
