l AC
1
/DC
2
Power Adapter
(PPP000000058020102)
(2)
(1) Required for pedal removal.
(2) Helpful to power the console for configuration or software uploads.
Specification Summary
This table provides a summary of system component specifications.
System Component Specification
Pedal Torque 33 ft-lb (45 N•m)
Belt Drive Tension 140 - 150 lbs
Chain Drive Tension 1/2 in (1.3 cm) up/dwn travel
Stabilizer fastener Torque 15.6 ft-lbs (21 N•m)
Axle Nut Torque 29.5 ft-lbs (40 Nm)
Parts
IMPORTANT: Always purchase OEM replacement parts and hardware from Precor.
If you use parts not approved by Precor, you could void the Precor Limited Warranty.
Use of parts not approved by Precor may cause injury.
Major Assembly and Parts Location
1
Alternating Current: electric current which periodically reverses direction between positive
and negative polarity.
2
Direct Current: electrical current that only flows in one direction.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 4
2 General Information
Specification Summary
