Resistance Knob Replacement
About
This procedure provides instruction to remove and install the Resistance Knob assembly.
The resistance knob is fixed to the steel resistance shaft capped with an acorn nut that applies
pressure to the leather brake pad assembly. The brake pad assembly must be removed to
access and remove the resistance shaft acorn nut.
ID Part
Resistance knob
Resistance shaft
Shaft acorn nut
Brake pad assembly
Procedure
Review entire procedure before starting.
Removal Instructions
1. Remove all resistance (pressure on the brake pad) by turning the resistance knob coun-
terclockwise (-) until it reaches the stop.
2.
Remove the brake pad assembly by removing the mounting bolts (2x) and washers
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 45
5 Replacement Procedures
Resistance Knob Replacement
