Installation Instructions.
9. Install the belt over the front flywheel pulley and rear pulley.
10. Use two service techs to carefully install the flywheel by inserting the axle mounting
plates into the frame axle mounting slots.
TIP: You may find it easier to stand the bike frame on its front (resting on the front sta-
bilizer and handlebar) and then installing the flywheel into the axle mounting slots.
The weight of the flywheel will help to slide the flywheel into the mounting slots.
Secure axle plate with mounting plate bolts and carefully return bike to the upright
position.
11. Position the flywheel to align the left and right axle mounting plate holes to the frame
mounting threads. Secure axle mounting plate with fasteners (2x each) using a 6
mm hex key.
12.
Tighten the left and right axle bolts , torque to 29.5 ft-lbs (40 Nm).
13.
Reinstall the frame cross member onto frame, make sure the drive belt is correctly
installed onto the tension mechanism pulleys. Secure with fasteners (4x) using 6 mm
hex key.
14.
Reinstall the rear belt pulley finger guard , secure with the fasteners (2x) using a 5
mm hex key.
15. Tension belt to specification, go to "Belt Drive Tension Adjustment" on page10.
NOTE:Make sure the frame cross member is installed before tensioning belt.
16. Verify that the brake pad is centered on the flywheel and operating correctly.
17. Replace front and rear belt guard covers, see "Belt/Chain Guard Cover Replacement"
on page19
18. Verify the bike operation per "Operation Verification Checklist" on page8 and return to
service.
See Also
"Replacement Procedures" on page17
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 24
5 Replacement Procedures
Belt and Flywheel Replacement
