4. Description of functions
Premier Tech 14 / 64 Solido SMART
DOKK5110E 15.04.2020
4.2 Component overview in rectangular tank M2
Shaft for desludging DN160
Air inlet
support
Technology capsule
Sampling pot with
overflow protection
Tube diffuser 1
Tube diffuser 2
Clearwater lifter
Baffle
Characteristics:
• chambers are connected
by openings in baffle
• both chambers are
aerated
• no slow down influent
• Desludging via pipe
DN160 (remaining
volume in second
chamber)
Openings
in baffle
Cut
Overfill sensor
